EXPLORR .224 Utility Mount (HUB) AM Silencer

Description

The EXPLORR® .224 Utility Mount AM Silencer is a highly durable .224cal (5.56mm) HUB-compatible suppressor constructed from Griffin’s proprietary Nickel 625X™ powder alloy utilizing state-of-the-art DMLS additive manufacturing technology. EXPLORR® suppressors have always excelled as a lightweight, highly accurate option for use on bolt and gas guns alike, and the new EXPLORR® AM generation maintains near-identical weights with a higher durability rating and longer lifespan.

These silencers are built on the industry-standard HUB mounting interface (1.375×24 TPI), allowing end users to customize their mounting system to fit their needs. EXPLORR® Utility Mount AM silencers are compatible with Griffin’s HUB Mount Interfaces, as well as other manufacturer’s inserts. These silencers are segmented as an ideal dual-purpose suppressor boasting impressive performance on bolt and gas-operated firearms.

The proprietary, patent-pending Nickel 625X™ alloy showed in testing a ~68% increase in yield and tensile strength over additively manufactured INCONEL® 625 at 1200°F.  INCONEL® 625 is a commonly used suppressor alloy in current next generation military suppressors.  Additively manufactured Nickel 625X™ is stronger at 1472°F than INCONEL® 625 cold formed sheet material at room temperature.  INCONEL® 625 cold formed material provided adequate service in the last several decades of military suppressors.

Features

• HUB-Compatible (1.375×24) Threaded Rear
• Latest Generation ECO-FLOW™ Baffle Stack
• Additive Manufactured Core
• Ultra-Durable Nickel 625X™ Alloy Construction
• Printed Core Laser-Welded to Machined Rear for Warranty Serviceability
• Integrated Flash Hider End Cap
• Highly Accurate with Minimal POI Shift and Minimal Weight
• Perpetual Lifetime Warranty™

What’s in the Box

• EXPLORR® .224 Utility Mount AM Silencer (.22cal)
• User’s Choice of HUB Mount (Optional Add-On Cost if desired)
• Branded Griffin Silencer Pouch

Mounting Options Available

Note: Griffin’s HUB Mount Silencers do NOT ship with a muzzle device, or HUB Mount Interface. If desired, a HUB Mount can be added to your order using the buttons above for an additional cost.

• Direct Thread HUB Adapter (5/8×24 or 1/2×28)

• PLAN-A™ Short Taper Mount HUB Adapter

Compatible with All Taper Mount Muzzle Devices (EXCEPT FlashComp, OTB Bayonet Flash Hider, and 2.75″ Flash Hider)

• PLAN-A™ Long Taper Mount HUB Adapter

Compatible with ALL Taper Mount Muzzle Devices.

• A2 HUB Mount Interface

Compatible with most mil-spec Colt-pattern A2 birdcages & ALL GATE-LOK™ Muzzle Devices

• GATE-LOK™ HUB Mount Interface

Compatible with most mil-spec Colt-pattern A2 birdcages & ALL GATE-LOK™ Muzzle Devices

• DUAL-LOK™ HUB Mount Interface

Compatible with ALL DUAL-LOK® Muzzle Devices (Excluding: Over-the-Barrel PSR™ Muzzle Devices and OTB Bayonet Open Tine Flash Hider)

AVAILABLE MAINTENANCE ITEMS:

• Bushwhacker Spanner Wrench (Recommended for installing Griffin HUB Mounts)
• Mount Adapter Driver
• Cleaning Brushes
• ST-3 Thread Sealant
• High Temp 2300 degree Anti Seize
• Alignment Rods (to verify proper installation)

Digital Manual

• CLICK HERE FOR MANUAL

Ratings & Restrictions

• EXPLORR® Suppressors do not have minimum barrel length restrictions or constraints for rifle calibers. While longer barrels promote longer service life, there are no barrel length restrictions with this suppressor!

INCONEL® is a registered trademark of Special Metals Corporation. Griffin Armament has no affiliation with Special Metals Corporation, and the use of “INCONEL®” is in this document is only for purposes of comparison between materials.
