Griffin Heads-Up Sight (GHS™)

Description

The Griffin Heads-Up Sight (GHS™) features a spacious, 38mm window and a crisp 3 MOA dot with 10 brightness settings. The fully-enclosed emitter is housed in a rigid, aluminum body with a rubber-cushioned aluminum roll cage to protect the sight from damage. Oversized brightness buttons are easy to use even when wearing gloves, and the integrated flip up lens caps protect the glass when not in use. The GHS™ is currently available in red illumination only.

The minimal parallax, clear sight picture of the GHS™ combined with 10 brightness settings makes target acquisition fast and natural in a variety of lighting conditions from bright sunny days, to dark cloudy nights. Settings 1 and 2 can be used as NV settings. Parallax is set at 25 yards. The sight can be turned off by holding the down arrow, and powered on by pressing the up arrow. This sight automatically goes into rest mode after 8 hours of inactivity, and features shake awake if not physically powered off by holding the down arrow.

The fully-housed IPX7 waterproof and shockproof aluminum sight body provides a robust frame to protect the optic from drops, dings, and bumps or even a swim. The black hardcoat Type 3 Anodized finish resists scuffs and abrasions to keep your sight looking its best amidst the toughest conditions. The Griffin Heads-Up Sight™ is ready for use right out of the box with the integrated picatinny mount and included CR123A battery.

What’s in the Box:

• Griffin Heads-Up Sight™ (Picatinny Mount) – 3 MOA Dot
• (1) CR123A Battery – Included
• Flip Up Lens Covers
• Allen Key Set
• Griffin Microfiber Cloth

Features:

• 3 MOA Dot Reticle
• 1 MOA Adjustment Increments
• 10 Brightness Settings (8 Daytime, 2 NV)
• Parallax Set at 25yds
• Flip-Up Plastic Lens Covers
• Integrated Picatinny Mount (Co-Witness Height)
• Shockproof (1200 Gs)
• Waterproof (IPX7 – 1 meter for 30 mins)
• Fogproof Internals
• 8 Hour Auto-Rest with Shake Awake
• 50,000 Hours of Battery Life at Level 1 | 20,000 hours at Level 6 | 1200 hours at Level 10
• Perpetual Lifetime Warranty™ (2 Years on Electronics)

Specs

• Magnification: 1x
• Window Size: 38x28mm
• Lens: Multi-Coated Glass
• Dot Size: 3 MOA
• Adjustment Increment: 1 MOA
• Max Elevation Adjustment: 90 MOA
• Max Windage Adjustment: 90 MOA
• Battery Type: (1) CR123A – Included
• Brightness Settings: 10 Levels (8 Daytime, 2 NV)
• Weight: 12 oz
• Dimensions: 3.00″L x 2.00″W x 3.00″H

Manual

CLICK HERE for manual
